Power ON Test
9650-0309-01 Rev. E ZOLL AED Pro Service Manual 1–5
3.0 Power ON Test
Equipment Needed
• Power Supply 12V 10A,
• AED PLUS, Quick-Test, Test Fixture (P/N 9100-0567-TF),
• Battery Current Test Fixture (P/N 9100-0690-TF) or AED Pro Disposable Battery (P/N
1008-002003-01).
Setup
• Connect AED PLUS Quick-Test Test Fixture (P/N 9100-0567-TF) to the unit.
Test Action Expected Result(s) Pass Fail
3.1 Place the AED Pro Battery in
the battery well (then turn on the
Power Supply if Battery Current
Test Fixture is used)
Initial Power up. Unit will turn off
by itself after UNIT OK prompt.
 
3.2
Press and hold the On/Off
button for at least 7 seconds,
then release it.
Within 10 seconds after the unit
is turned on, the Ready For Us
indicator displays a green
Check. Indicating the unit is
ready for use. A red “X”
indicates the unit is not ready for
use.
 
