Test Equipment
9650-0309-01 Rev. E ZOLL AED Pro Service Manual 1–17
11.3
Select from the DCI
commander:
SECAL, Enter 0 in 'Parm 1
(val)' window to remove the old
offset and resets to zero offset.
Click on “Send”
Select from the DCI commander
1:
GEVOL, Enter 2000 in 'Parm 1
(val)' window. Select from the
DCI commander 2: GECAL
again to get the new offset value
(VOL). Click on “Send”
Select from the DCI
commander:
SECAL, - (VOL) [SECAL,
minus (VOL)] to set new ECG
offset calibration. ENTER.
Click on “Send”
The response will be: SECAL,
OK
 
11.4
Select from the DCI commander
1:
GEVOL Enter 2000 in 'Parm 1
(val)' window; Select from the
DCI commander 2: GECAL
and click on "Send".
The response will be:
GEVOL,0 +/-2.5 counts;
GECAL, (new offset #)
 
11.5
To save Calibration, Select from
the DCI commander:
SFCAL
The response will be SFCAL,
OK
 
