Zoom V6 User Manual

Turning the power on
1.
Minimize the volume of output devices.
2.
Set to ON.
This turns the
on, and lights green.
3.
Raise the volume of output devices.
HINT
•4 AA batteries can also be used. Use only one type of battery (alkaline, NiMH or lithium) at a time. (
“Using batteries” on page 13)
•Power for operation can also be supplied through the USB port.
ECO mode overview
•By default, ECO mode is set to ON, so the power will automatically turn off if no use occurs for 10
hours.
•ECO mode can also be set to OFF on the SETTING screen. ( “Setting ECO mode to turn the power off
automatically when not used” on page 31)
12

Zoom V6 Specifications

General

Type	Vocal Processor
Looper	Yes
Inputs	1 x XLR
Phantom Power	Yes
USB	Yes
Computer Connectivity	USB
Input Channels	1
Output Channels	2
Bit Depth	24-bit
Sample Rate	44.1 kHz
Headphone Output	Yes
Input	XLR
Power	9V DC
Power Source	9V DC power supply (included)
Outputs	2 x XLR
