Zoom V6 User Manual

Specications
VOICE section 12 types
EFFECT section 10 types
HARMONY section 5 types
Number of patch memories 100
Sampling frequency 44.1 kHz
A/D conversion 24-bit 128× oversampling
D/A conversion 24-bit 128× oversampling
Signal processing 32-bit
Frequency response 20 Hz–20 kHz (+1 dB/−3 dB) (200 kΩ load)
Display 2-digit 7-segment LED
Input SGV-6 Directionality: Super cardioid (3 directional mic units)
Sensitivity: –46 dB/Pa at 1 kHz (each mic unit)
Maximum sound pressure input: 140 dBSPL
MIC IN XLR jack
Input gain: +3 – +40 dB
Maximum input level: +4 dBu
Input impedance: 3 kΩ or higher (1 kHz)
Phantom power: +48 V
Outputs OUTPUT XLR jack
Maximum output level: +8 dBu
Output impedance: 50 Ω (HOT-GND, COLD-GND, 1 kHz)
100 Ω (HOT-COLD , 1 kHz)
GROUND LIFT (switchable)
PHONES Stereo mini jack
Maximum output level:
20 mW + 20 mW (into 32 Ω load)
Equivalent input noise (when phan-
tom power off)
–125 dBu or less (A-weighted, 150 Ω input, +40 dBu input gain)
Noise oor (residual noise) –75 dBu
Control input FP02 input
Power AC adapter (9 V DC 500 mA, center negative) (ZOOM AD-16)
4 AA batteries (about 3.5 hours continuous operation time when using alkaline batteries)
USB Connector: Micro USB
Audio interface operation: 2-in/2-out USB2.0 Full Speed, 44.1 kHz, 16/24/32-bit
•PowercanalsobesuppliedthroughtheUSBport.
•Whenusingacabledesignedonlyforpower,otherUSBfunctionscannotbeused.
External dimensions 181 mm (D) × 320 mm (W) × 77 mm (H)
Weight 1.56 kg (excluding batteries)
Optional FP02 expression pedal
Note: 0 dBu = 0.775 V
38

Zoom V6 Specifications

General

Type	Vocal Processor
Looper	Yes
Inputs	1 x XLR
Phantom Power	Yes
USB	Yes
Computer Connectivity	USB
Input Channels	1
Output Channels	2
Bit Depth	24-bit
Sample Rate	44.1 kHz
Headphone Output	Yes
Input	XLR
Power	9V DC
Power Source	9V DC power supply (included)
Outputs	2 x XLR
