2Wire Gateway - Changing Timeout Parameters; Enabling Broadband Status Notification; Enabling Missing DSL Filter Notification; Enabling SIP Application Layer Gateway

Management and Diagnostic Console
108
5. Click the Enable Routing checkbox.
6. Click the Submit Settings button.
The gateway PPP, routing, and TCP/IP functions are now re-enabled, and the Local Network LED will turn
Green. The computer can now be reset to a DHCP-assigned IP address, or left to obtain it statically.
Changing Timeout Parameters
By default, TCP and UDP are configured to timeout in 1,440 and 10 minutes, respectively. You can change
the parameters by entering different values in the TCP Timeout and UDP Timeout fields, and then clicking
the
Submit button.
Enabling Broadband Status Notification
Note: This field will display only if the CMS organization has the Broadband Status Notification feature
enabled.
To receive a notification message that the gateway has lost broadband connectivity and cannot access the
Internet, check the
Enable checkbox.
Enabling Missing DSL Filter Notification
Note: This field will display only if the CMS organization has the Missing DSL Filter Notification feature
enabled.
To receive a notification message that the gateway has detected a missing DSL filter, check the
Enable
checkbox.
Enabling SIP Application Layer Gateway
To enable the SIP ALG on the gateway firewall, check the Enable checkbox.
Changing the Upstream MTU
The MTU (Maximum Transmission Unit) is the largest size packet or frame, specified in octets (eight-byte
bits), that can be sent from a computer to the network. The 2Wire gateway’s MTU varies, depending on the
connection type used (for example, PPP or direct IP).
To change the gateway’s upstream MTU:
1. In the Force Upstream MTU field, enter the value specified by the service provider.
2. Click the Submit button.
