7. From the Application Type pull-down menu, select the application type: None (Default), File Transfer
Protocol (FTP), Microsoft Games, H.323-based Internet telephony, IRC (Internet relay chat) server, or
PPTP virtual private network server.
8. Click the Add Definition button.
9. Repeat the previous step for each port or range of ports required for the application profile.
Allowing all applications
DMZplus is used for hosting applications if an application will not operate properly using the “Allow
individual application(s)” option. When in DMZplus mode, the designated computer:
• Shares the gateway’s IP address.
• Appears as if it is directly connected to the Internet.
• Has all of the unassigned TCP and UDP ports opened and pointed to it.
• Can receive unsolicited network traffic from the Internet.
Note: DMZplus can only be configured for one computer on the local network at a time.
To configure a computer on the user’s network for DMZplus mode:
1. Select the computer to which the user wishes to have all data sent.
2. Click the Allow all applications (DMZplus mode) radio button.
3. Click Submit.
4. Access the selected computer.
5. Confirm that the computer is configured for DHCP. If it is not, configure it for DHCP.
6. Restart the computer.
When the computer restarts, it receives a special IP address from the system and all unassigned TCP and
UDP ports are forwarded to it.
