PROCEDURES STATUS
IN THE CONTROL AREA
STEP 1:
Select the operative mode and confirm it (see User Manual).
STEP 2:
Take a note about which length you want to correct from the Load Chart; for
example you take this length: 10,3m/ 17,2m/ 24,2m/ 31,0m/ 32,6m.
STEP 3:
Move the boom length like the first value (for Example 10,3m); put the boom at
70 °; to unload any weight (to move only the winch, NOT the boom angle),
remain only with the hook.
STEP 4:
Measure the radius (to start from center of the turret to center of hook); you
have to go on the “Radius Act” page and insert the value.
WEIGHT CALIBRAT 0
Radius Act 12.50
STEP 5:
Insert the value of the Hook weight.
WEIGHT CALIB. 0
Hook Weight .60
When you have finished, press the key, to beginning the “Empty
Calibration”.
WEIGHT CALIB. 200
Hook Weight .60
when this operation is finished the command will become 0 and it will be
possible to jump on the next step.
WEIGHT CALIB. 0
Hook Weight .60
STEP 6:
without move the boom angle, lift a weight; measure the radius like STEP 4;
insert the value just measured inside the “Radius Act” menu.
WEIGHT CALIBRAT 0
Radius Act 13.50
STEP 7:
Go to the “Lift Weight” menu and enter the value of the weight that you want to
lift.
WEIGHT CALIB. 0
Lift Weight 2.60
Press the key to begin.
WEIGHT CALIB. 100
Lift Weight 2.60
