Top view
1
2
3
4
5
6
7
1
2
3
4
5
6
7
3/8” inserts
«Sh» tool
«Pitch» tool
Magazine’s upper lock
Collimation cap
Viewfinder friction screw
Tape hook
Socket for accessories
Shutter angle adjustment tool
Pulldown pitch adjustment tool
Secures the magazine to the camera body
Gives access to ground glass collimation adjustment
Adjusts the viewfinder up-down freedom of movement
Holds the focus distance tape on the gate plane
