Front view
1
2
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
Short eyepiece
Horizon setting knob
Friction adjusting ring
Fischer-2 connector
PL mount locking ring
LEMO-2 connector
Rosette
Video (VHR) ND knob
Video housing
Top rod holder
(Extension eyepiece to be ordered separately)
To adjust the image horizon
To adjust the tension of the eyepiece swivel
Eyepiece heating cable connector
Lock ring for 35mm PL mounted lenses
Run/Stop connector
For accessories compatible with ARRI rosettes
To adjust the video light level
Protects the CCD unit
To install a rod (15, 15.8 or 19mm)
