Installing the magazine
To install the magazine, stay at the rear of the camera body, Operator’s side.
Place your right hand underneath the magazine while your left hand is firmly
holding it at the midway point of its rear. Rest the nose of the magazine on
the camera base, hold the camera body with your left hand while pushing
the mag in the bottom dovetail and into the aperture area with your right
hand. Make sure that the top of the nose of the mag is parallel to the cam-
era as you guide the mag in place. Push firmly and evenly until you feel and
hear that the mag snaps against the aperture area.
Don’t forget to lock the magazine by pushing the magazine upper locking
lever.
Removing the magazine
To remove the magazine, stay at the rear of the camera body, Operator’s
side. Unlock the magazine upper lock lever and push the magazine release
lever (A) toward the front of the camera.
Pull the mag off the camera body.
