70 “Operation and installation manual” - “Terra 360 Series 2 - CE”
EN
EVSE Terra 60 CCT
AC Input
Input connection 3 Phases + N + PE
Input voltage 400 Vac +/- 10%
Input frequency 50 Hz
Input Current 125 A
Input power 86KVA
Power Factor > 0.96 @ full load
Harmonic Distortion (THD) 4.5% at full output power
Earthing systems TN-S, TN-C, TN-C-S, TT (with upstream RCD)
Overvoltage category III
Protection
Overcurrent, overvoltage, undervoltage, ground
fault including DC leakage protection,
overtemperature, integrated surge protection
SPD - According to EN 61643-11 and IEC 61643-11 Yes, Type 2 / Class 2
SPD - Nominal discharge current (8/20 us) [L-N] / [N-PE] 20 kA / 80 kA
SPD - Short-circuit withstand capability (ISCCR) 25 kA
Short circuit current 25 kA
Tilt sensor (option)
Voltage input 20...24 V DC
Power consumption Max 30 mA
Reverse polarity protection Yes
Mechanical
Dimensions (D x W x H) 565 x 1210 x 2215 mm
Mounting Type Floor mounted
Maximum tilt angle - Transport 15°
Weigth - based on cabel type 480 kg
Enclosure type Stainless steel 430 and Aluminium
IK rating according to IEC 62262 IK10 (HMI: IK08)
Environmental
IP rating IP54
Enclosure Type Indoor and Outdoor
Maximum operating altitude up to 2000 m
Temperature range
-35 °C ... +55 °C
(de-rating characteristic applies from 40°C)
Storage conditions -5°C ... +40°C with RH 5% ... 95% @30°C
Operating humidity 5...95 % RH non-condensing
Noise level
<65 dB(A) at 1m distance @25°C on front door, at
full power
Interface
Screen Type 15" LCD high-contrast touchscreen
Languages
Standard Language English ( Others available via
Software upgrade)
Cellular communication GSM / 4G / LTE
Communication Protocol
Open Charger Point Protocol (OCPP) 1.6 (and
previous versions)
Athentication methods
"RFID ( Standards, Cards.)
On-screen PIN code authorization
Option: payment terminal; Prepared for ISO
15118 - 2 PnC"
RFID system
Mifare ISO 14443 A+ B to part 4 and ISO/IEC
15693
Others available on request (NFC, Calypso,
Ultralight, PayPass, HID; and more)
Energy metering
Ready for Eichrecht/PTB and MID compliancy for
AC and DC outlets
Emergency stop button type On request
