71Technical data
EN
EVSE Terra 60 CCT
Standards
Declaration of Conformity CE
Low voltage Directive
EN 61851-1:2011, EN 61851-23:2014, IEC 61851-
1:2010, IEC 61851-23:2014, EN IEC 61851-1:2019,
IEC 61851-1:2017
EMC EN IEC 61851-21-2:2021, IEC 61851-21-2:2018
RED
EN 300330 V2.1.1:2017, EN 301908-13
V11.1.2:2017, EN IEC 62311:2020, EN 50364:2018
Additional compliace with standards
1
IEC 62196-2, IEC 62196-3
Communication to the EV DIN 70121, ready for ISO 15118 - 2 Plug’n’Charge
1. ABB uses AC cables/connectors from suppliers, who also declare compliance with this standard
10.1.2 Technical data table - Terra 360
EVSE Terra 360 CC
Connector
Charging standard (IEC 61851-1) Mode 4
Number of outputs 2
Number of EV served Up to two EV in parallel
Output combinations 2x CCS 2 connectors
Cable type Air cooled cable
Cable Length Standard: 4.7 m
Efficiency > 95% at nominal output power
DC Output
DC output power 360kW (peak)
DC output voltage CCS 150...920 VDC
DC output current
Nominal 300A DC
Peak 500A DC
Overvoltage category II
AC Input
Input connection 3 Phases + PE
Input voltage 400 Vac +/- 10%
Input frequency 50 Hz
Input Current 560 A
Input power 390KVA
Power Factor > 0.96 @ full load
Harmonic Distortion (THD) 4.5% at full output power
Earthing systems TN-S, TN-C, TN-C-S, TT (with upstream RCD)
Overvoltage category III
Protection
Overcurrent, overvoltage, undervoltage, ground
fault including DC leakage protection,
overtemperature, integrated surge protection
SPD - According to EN 61643-11 and IEC 61643-11 Yes, Type 2 / Class 2
SPD - Nominal discharge current (8/20 us) [L-N] / [N-PE] 20 kA / 80 kA
SPD - Short-circuit withstand capability (ISCCR) 25 kA
Short circuit current 25 kA
Tilt sensor (option)
Voltage input 20...24 V DC
Power consumption Max 30 mA
Reverse polarity protection Yes
