72 “Operation and installation manual” - “Terra 360 Series 2 - CE”
EN
EVSE Terra 360 CC
Mechanical
Dimensions (D x W x H) 764 x 1210 x 2215 mm
Mounting Type Floor mounted
Maximum tilt angle - Transport 15°
Weigth - based on cabel type 848 kg
Enclosure type Stainless steel 430 and Aluminium
IK rating according to IEC 62262 IK10 (HMI: IK08)
Environmental
IP rating IP54
Enclosure Type Indoor and Outdoor
Maximum operating altitude up to 2000 m
Temperature range
-35 °C ... +55 °C
(de-rating characteristic applies from 40°C)
Storage conditions -5°C ... +40°C with RH 5% ... 95% @30°C
Operating humidity 5...95 % Rh non-condensing
Noise level
<75 dB(A) at 1m distance @25°C on front door, at full
power
Interface
Screen Type 15" LCD high-contrast touchscreen
Languages
Standard Language English ( Others available via
Software upgrade)
Cellular communication GSM / 4G / LTE
Communication Protocol
Open Charger Point Protocol (OCPP) 1.6 (and
previous versions)
Athentication methods
“RFID ( Standards, Cards..)
On-screen PIN code authorization
Option: payment terminal; Prepared for
ISO 15118 - 2 PnC”
RFID system
Mifare ISO 14443 A+ B to part 4 and
ISO/IEC 15693
Others available on request (NFC, Calypso,
Ultralight, PayPass, HID; and more)
Energy metering
Ready for Eichrecht/PTB and MID compliancy for
AC and DC outlets
Emergency stop button type On request
Standards
Declaration of Conformity CE
Low voltage Directive
EN 61851-1:2011, EN 61851-23:2014, IEC 61851-
1:2010, IEC 61851-23:2014, EN IEC 62311:2020
EMC
EN IEC 61000-6-1: 2019, EN 61000-6-4:2007+A1,
IEC 61851-21-2:2018, EN 301489-1 v2.2.3:2019
RED
EN 300330 V2.1.1:2017, EN 301908-13
V13.1.1.2019, EN 50364:2010, EN 301489-3
V2.1.2:2021, EN 301489-52 V1.1.2:2020, EN
301908-2 V13.1.1:2020, EN IEC 62311:2020
Additional compliace with standards
1
IEC 62196-2, IEC 62196-3
Communication to the EV DIN 70121, ready for ISO 15118 - 2 Plug’n’Charge
1. ABB uses AC cables/connectors from suppliers, who also declare compliance with this standard
