2600T SERIES | PRESSURE TRANSMITTERS | OI/266/FF-EN REV. E
21
B6 and B7 Barrel housing bracket details
66 (2.60)
1/2 - 14 NPT
122 (4.80)29 (1.14)
18 (0.71)
117 (4.60)
30 (1.19)
72 (2.83)
11 (0.43)
128 (5.04)
85 (3.35)
18 (0.71)
145 (5.71)
54 (2.13)
Ø65 (2.56)
39 (1.54)
16 (0.63)
18 (0.71)
72 (2.83)
49 (1.93)
105 (4.13)
32 (1.26) width across
flats of exagon
U-bolt
Transmitter fixing bolts
U-bolt fixing bolt and washer
B1 or B2 bracket
U-bolt
U-bolt fixing bolt and washer
Transmitter fixing bolts
B1 or B2 bracket
Fitting adapter
