22 266CRH / 266CRT, 266CSH / 266CST MULTIVARIABLE PRESSURE TRANSMITTER | OI/266CXX/MODBUS-EN REV. A
… 6 Installation
… Mounting dimensions – Model 266CSx
Transmitter with barrel housing – vertical flanges
M10139-01
142 (5.59)
54 (2.13)
91 (3.58)
31 (1.22)
251 (9.88)
216 (8.50)
18 (0.71)
28 (1.10) LCD (L1)
24 (0.95) TTG-LCD (L5)
53 (2.09)
9 (0.35)
110 (4.33)
18 (0.71)
41,3 (1.63)
1 2
3
4
5
6
9
8
0
7
1 Push buttons
2 Name plate
3 Certification plate
4 Vent / drain valve
5 Process connection
6 Terminal side
7 LCD display housing cover
8 Electronics side
9 Process flange adapter
0 Space for removing the cover
Figure 9: Barrel housing – vertical flanges, Dimensions in mm (in)
