44 266CRH / 266CRT, 266CSH / 266CST MULTIVARIABLE PRESSURE TRANSMITTER | OI/266CXX/MODBUS-EN REV. A
… 8 Operation
Menu levels
Process display
Operator Menu Configuration
Diagnostic Easy Setup
Operator Page MV Setup - Mass Flow
Signals View
MV Setup - open Tank
MV Setup - closed Tank
MV Setup - Steam Drum
Level
MV Setup - 2 Remote Seals
Device Setup
MV Overview
Display
Process Alarm
Calibration
Totalizer
Diagnostic
Device Identify
Communication
Process display
The process display shows the current process values.
There are two menu levels under the process display.
Information level (Operator Menu)
The information level contains the parameters and information
that are relevant for the operator.
The device configuration cannot be changed on this level.
Configuration level (Configuration)
The configuration level contains all the parameters required for
device commissioning and configuration. The device
configuration can be changed on this level. For detailed
information on the parameters, see .
Process display
M10819-01
PI-AX-1001
mbar
278.75
%
1
3 3
2
5
4
1 Measuring point tag
2 Current process values
3 ‘Button function’ icon
4 ‘Parameterization protected’ icon
5 Diagnostics message
Figure 35: Process display (example)
The process display appears on the LCD display when the device
is switched on. It shows information about the device and
current process values.
The way in which the current process values are shown can be
adjusted on the configuration level.
The symbols at the bottom of the process display are used to
indicate the functions of the operating buttons and , in
addition to other information.
Symbol Description
Call up information level.
Call up configuration level.
The device is protected against changes of the parameter
settings.
