Optional I/O extension modules 149
15
Optional I/O extension modules
Contents of this chapter
This chapter describes how to install and start up the optional CHDI-01, CMOD-01 and
CMOD-01 IO extension modules. The chapter also contains their diagnostics and
technical data.
CHDI-01 115/230 V digital input extension module
 Safety instructions
WARNING! Obey the safety instructions for the drive. If you ignore the safety
instructions, injury or death can occur.
 Hardware description
Product overview
The CHDI-01 115/230 V digital input extension module expands the inputs of the drive
control unit. It has six high voltage inputs and two relay outputs.
