Electrical installation

7. Undo the screw connecting the grounding wire to a standoff right next to the EMC

filter. Cut off the lug. Discard the screw and the tubular insulator.

8. Insulate the end of the grounding wire reliably with insulating tape, tube sleeving

and a cable tie.

Standoff covered by

insulator

EMC filter
