Active component selection
Menu path
MENU → Configure → Component-specific → Active Component
Active component
The "Active component" parameter appears with the Caldos25, Caldos27,
Fidas24, Magnos206, Magnos28 and Magnos27 analyzer modules.
Several sample components can be calibrated on these analyzer modules.
However, there is always only one component measured and indicated.
Procedure
Select the active component with the arrow keys and press ENTER to con-
firm.
Subsequently, use the "Measurement range" menu item to select the range
for the desired active component.
NOTE
The selected active component and measurement range are shown on the
screen after switching to measurement mode.
