AO2000 CONTINUOUS GAS ANALYZERS | OI/AO2000-EN REV. B 155
Gas analyzer configuration: Measurement
component-specific functions
Measurement range configuration
Measurement range switch-over
Menu path
MENU → Configure → Component-Specific → Measurement Range →
Select Component → ...
Selection
All measurement ranges configured (at the factory) for a sample component
are displayed.
Procedure
Select the measurement range with the arrow keys and press ENTER to
confirm.
NOTE
The measurement range selected is shown on the screen after switching to
measurement mode.
