308 AO2000 CONTINUOUS GAS ANALYZERS | OI/AO2000-EN REV. B
Lamp (EDL) replacement
2
4
1
4
3
21
4
6
5
4
3
789 10
1
1
3
1
Light barrier circuit board 1
2
Light barrier circuit board 2
3
Lamp (EDL)
4
Fastening screws of the support
5
Fastening screws of the lamp
6
Support
7
Temperature sensor block
8
Fastening screw of the temperature sensor
9
Temperature sensor
10
12-V-supply connector
11
Fastening screws of the heater block
