AO2000 CONTINUOUS GAS ANALYZERS | OI/AO2000-EN REV. B 333
Temperature problem
Gas analyzer still in warm-up phase
• The duration of the warm-up phase depends on which analyzer module
is installed in the gas analyzer.
Analyzer module Duration of the warm-up phase
Caldos25 1.5 hours
Caldos27 30/60 minutes for class 1/2 measurement ranges
1)
Fidas24 ≤ 2 hours
Fidas24 NMHC ≤ 2 hours
Limas11 IR Approx. 2.5 hours
Limas21 UV Approx. 2.5 hours
Limas21 HW Approx. 4 hours
Magnos206 ≤ 1 hour
Magnos28 ≤ 1 hour
Magnos27 2 to 4 hours
Uras26 Approx. 0.5/2 hours without/with thermostat
ZO23 Approx. 15 minutes
1) See "AO2000 Series" data sheet for class details.
Excessive air movement
• Reduce the flow of air around the gas analyzer.
• Install shielding against drafts.
Ambient temperature outside of permissible range
• Protect the gas analyzer from cold and heat sources such as the sun,
ovens and
• Observe climatic conditions
Relative humidity max. 75 %,
no condensation
Ambient temperature for storage and transport
with integrated oxygen sensor
−25 to +65 °C
−25 to +60 °C
Ambient temperature range during operation with
Analyzer module installed in a housing
without electronics
module
installed in a housing with
electronics module or with
power supply only
Caldos25 +5 to +45 °C +5 to +45 °C
Caldos27 +5 to +50 °C +5 to +45 °C
Fidas24 +5 to +45 °C +5 to +45 °C
Fidas24 NMHC +5 to +40 °C +5 to +40 °C
Limas11 IR +5 to +45 °C +5 to +45 °C
1)
Limas21 UV +5 to +45 °C +5 to +45 °C
1)
Limas21 HW +15 to +35 °C +15 to +35 °C
Magnos206 +5 to +50 °C +5 to +45 °C
Magnos28 +5 to +50 °C +5 to +45 °C
Magnos27 +5 to +45 °C
2)
+5 to +45 °C
Uras26 +5 to +45 °C +5 to +40 °C
ZO23 +5 to +45 °C +5 to +45 °C
Oxygen sensor
in 19-inch housing
in wall-mount
housing
+5 to +40 °C
+5 to 35 °C
+5 to +40 °C
+5 to +35 °C
1) +5 to +40 °C when I/O modules are installed
2) +5 to +50 °C for sample chamber direct connection and installation in
housing without electronics module or Uras26
