…2.3 Operating Page
2.3.3 Wash Function
Note. The Wash function is available only if A3: Type is set to Wash – see Section 5.5.
Wash Function
Off –Wash function off. Lower display line of Operating Page shows
WASH INHIBITED.
On –Wash function controlled automatically. Lower display line of Operating Page
shows
WASH IN PROGRESS.
Manual – Enables wash function to be initiated manually – see below.
Note. Set
Wash Function to Off before removing the sensor from the process.
See Section 3.1.
See Section 4.1.
Wash Function set to Manual – see below.
Wash Function not set to Manual. The display returns to the top of the
Operating Page.
Press to Wash (Manual Wash only)
Press to Wash and Press to Abort are shown alternately on the lower display line.
Press the key to initiate the wash cycle. The display returns to the top of
the Operating Page and the lower display line shows
WASH IN PROGRESS until
the wash cycle is completed. The
Wash Function selection reverts to the one
that was set before
Manual was selected.
Press the
key to abort the wash cycle. The display returns to the top of
the Operating Page.
VIEW SETPOINTS
SENSOR CAL.
Wash Function
-----
Manual
On
Off
-----
Press To Wash
Press To Abort
Press To Wash
Diss. Organics
WASH IN PROGRESS
Diss. Organics
…2 OPERATION
To Next Page
