…2.3 Operating Page
2.3.2 Dual Input Dissolved Organics
Measured Values in Inferred Units
Sensor A reading in inferred units, e.g.
Colour (°H). For units available, refer to Inferred Units
in Section 5.3.
Sensor B reading in inferred units.
Note. If
Lamp Disabled (see below) is set to Yes, Lamp Disabled is shown in the lower
display line and no values are displayed.
Equivalent Values in mgl
–1
Sensor A.
Sensor B.
Note. If
Lamp Disabled (see below) is set to Yes, Lamp Disabled is shown in the lower
display line and no values are displayed.
Disabling the Lamp – Sensor A
UV
Warning. Disable the lamp before performing any maintenance on the sensor –
see also
Warning on page 2.
If Yes is selected, Lamp Disabled is shown in the lower display line.
Disabling the Lamp – Sensor B
UV
Warning. Disable the lamp before performing any maintenance on the sensor –
see also
Warning on page 2.
If
Yes is selected, Lamp Disabled is shown in the lower display line.
Manual Cleaning – Sensor A
Select
Yes to initiate the Sensor A cleaning system.
Manual Cleaning – Sensor B
Select
Yes to initiate the Sensor B cleaning system.
See Section 3.1.
See Section 4.2.
A3: Type set to Wash (Section 5.4.) – See Section 2.3.3.
A3: Type not set to Wash (Section 5.4.) – Return to the top of the page.
Diss. Organics
1.25
H
1.25
H
Diss. Organics
10.25
mg/l C
10.25
mg/l C
Manual Clean
Sen. B
-----
VIEW SETPOINTS
SENSOR CAL
Lamp Disabled
Sen. A
-----
Yes
No
Yes
No
Lamp Disabled
Sen. B
-----
Yes
No
Manual Clean
Sen. A
-----
Yes
No
WASH FUNCTION
Diss. Organics
2 OPERATION
To Next Page
