ABB AV410 - Operating Page; Single Input Dissolved Organics

6
…2 OPERATION
2.3 Operating Page
2.3.1 Single Input Dissolved Organics
Measured Values
Reading in inferred units, e.g.
Colour (°H). For units available, refer to Inferred Units in
Section 5.3.
Concentration of dissolved organics in mgl
–1
.
Note. If
Lamp Disabled (see below) is set to Yes, Lamp Disabled is shown in the lower
display line and no values are displayed.
Disabling the Lamp
UV
Warning. Disable the lamp before performing any maintenance on the sensor –
see also
Warning on page 2.
If
Yes is selected, Lamp Disabled is shown in the lower display line.
Manual Cleaning
Select
Yes to initiate the sensor cleaning system.
See Section 3.1.
See Section 4.2.
A3: Type set to Wash (Section 5.4.) – See Section 2.3.3.
A3: Type not set to Wash (Section 5.4.) – Return to the top of the page.
Diss. Organics
1.25
H
10.25
mg/l C
Manual Clean
Sen. A
-----
VIEW SETPOINTS
SENSOR CAL
WASH FUNCTION
Lamp Disabled
Sen. A
-----
Yes
No
Yes
No
Diss. Organics
