AWT420 | UNIVERSAL 4-WIRE, DUAL-INPUT TRANSMITTER | OI/AWT420-EN REV. B
… 13 Configuration (Advanced access level)
… Control
Menu Comment Default
…Sensor 1 (2)
Base Controller If Control ActionDual-acting.
Setpoint (SPB)  PV range low
Control Type P, P+I. P
Proportional Band  
Integral Action Time If Control TypeP+I:
• 

Output Type Analog, Time Proportioning, Pulse Frequency. Analog
Cycle Time If Output TypeTime Proportioning:
• 

Pulse Frequency If Output TypePulse Frequency:
• 

Power Recovery
Recovery Mode Auto, Manual, Last. Auto
Default Output If Recovery ModeManual:
• Numeric value
If Control ActionReverse- or Direct-Acting:
• 
If Control ActionDual:
• 

Sensor Failure
Action  None
Default Output If Sensor Failure ActionDefault Output:
• Numeric value
If Control ActionReverse- or Direct-Acting:
• 
If Control ActionDual:
• 

PID 2 
Operator Control

Enabled
