AWT420 | UNIVERSAL 4-WIRE, DUAL-INPUT TRANSMITTER | OI/AWT420-EN REV. B
95
EZLink
Power consumption (maximum)
Fixed length cable
1 or 10 m (3.28 or 32.8 ft)
Digital sensor connector IP rating
IP67 (when connected)
Extension cable (options)
1, 5, 10, 15, 25, 50 m (3.2, 16.4, 32, 49.2, 82, 164 ft)
Maximum length (including optional extension cable)
Up to 210 m (826 ft)
EMC
Emissions & immunity
Meets requirements of IEC61326 for
an industrial environment
Approvals, certification and safety
Safety approval
cULus
CE mark
(including latest version IEC 61010)
General safety
• IEC 61010-1
• Pollution degree 2
• Insulation class 1
Bluetooth
The Bluetooth Low Energy Module within the AWT420
transmitter has received the regulatory approval for the
following countries:
• Europe/CE
Europe
• Japan/MIC: 005-101150
Japan
005-101150
Contains transmitter module with certificate number:
• Korea/KCC: MSIP-CRM-mcp-BM71BLES1FC2
Korea
MSIP-CRM-mcp-BM71BLES1FC2
•
China
CMIIT ID: 2016DJ5890
