OPC Server supports three internal data object types that provide status information:
•
3.4.7.2, Integer status (INS)
•
3.4.7.4, Single point status (SPS)
•
3.4.7.3, Controllable single point (SPC) for OPC internal data
Integer status (INS)3.4.7.2.
Table 3.4.7.2-1
DescriptionValue or Value range/ DefaultProperty/Para-
meter
Basic
Common data class according to IEC
61850
INSCommon Data
Class
Addresses
Item tag path for the internal status
information. The internal server tags that
can be used are located in the Attributes
nodes that are located under the root, line
and IED nodes. When an attribute tag is
referred to in the internal item definitions
below, it is possible to use either the whole
tag path or just the path relative to the IED
(the internal tags are configured per IED);
e.g. Attributes\Diagnostic counters\Trans-
mitted data messages. When the whole
path is used, it must be preceded by a
slash (/) character, e.g. /Channel
Name\Attributes\Diagnostic counters\Trans-
mitted data messages
Default: NoneItem Tag Path
Controllable single point (SPC) for OPC internal data3.4.7.3.
Table 3.4.7.3-1 Configurable SPC (for OPC internal data) properties for OPC Servers
DescriptionValue or Value range/ DefaultProperty/Para-
meter
Basic
Common data class according to IEC
61850
SPCCommon Data
Class
Addresses
28
1MRS756566
COM600 Station Automation Series
DNP 3.0
LAN/WAN Master
(OPC) 3.2
User's Guide
