ABB COM600 Station Automation Series User Manual

Integer status (INS)3.4.8.13.
Table 3.4.8.13-1 Configurable INS properties for OPC client
DescriptionValue or Value range/ DefaultProperty/ Para-
meter
Basic
Common data class according to IEC
61850.
INSCommon Data
Class
Addresses
Index.-1 to 65535
Default: -1
Index
Data Class Spe-
cific
Object number for indication.Analog input (30, 32)
Analog output (40)
Default: Analog input (30, 32)
Indication Object
Scale and Unit
Scale to be used with this type.Default: NoneScale
Integer controlled step position information (ISC)3.4.8.14.
Table 3.4.8.14-1 Configurable ISC properties for OPC client
DescriptionValue or Value range/ DefaultProperty/ Para-
meter
Basic
Common data class according to IEC
61850.
ISCCommon Data
Class
Addresses
Control index.-1 to 65535
Default: -1
Control Index
Indication index.-1 to 65535
Default: -1
Indication Index
Data Class Spe-
cific
Object number for control.Default: Analog control output
block (41).
Control Object
39
DNP 3.0
LAN/WAN Master
(OPC) 3.2
COM600 Station Automation Series
1MRS756566
User's Guide
