DescriptionValue or Value range/ DefaultProperty/ Para-
meter
Phase BC Index-1 to 65535
Default: -1
Phase BC Index
Phase CA Index-1 to 65535
Default: -1
Phase CA Index
Sub-Type
DEL SubtypeDEL SimpleSubtype
Data Class Spe-
cific
Object number for indication.Analog input (30, 32)
Analog output (40)
Default: Analog input (30, 32)
Indication Object
Scale and Unit
Specifies the multiplier for current SI unit.Default: DekaPhase Multiplier
Specifies the number of decimals shown
in HSI.
0 to 9
Default: 0
Phase Number of
Decimals
Scale to be used with this type.Default: NoneScale
SI unit for measurement as described in
IEC61850
Default: DimensionlessUnit
Table 3.4.8.8-2 Additional configurable properties for Sub-Type Limit Check
DescriptionValue or Value range/ DefaultProperty/ Para-
meter
Sub-type of current data objectDEL FullSub-Type
Limit Value Super-
vision
High limit for measurement. Event is cre-
ated when value crosses the limit.
Default: 0High
High-high limit for measurement. Event is
created when value crosses the limit.
Default: 0High-High
Low limit for measurement. Event is cre-
ated when value crosses the limit.
Default: 0Low
Low-low limit for measurement. Event is
created when value crosses the limit.
Default: 0Low-Low
35
DNP 3.0
LAN/WAN Master
(OPC) 3.2
COM600 Station Automation Series
1MRS756566
User's Guide
