DescriptionValue or Value range/ DefaultProperty/ Para-
meter
Object number for indication.Analog input (30, 32)
Analog output (40)
Default: Analog input (30, 32)
Indication Object
Scale and Unit
Specifies the multiplier for the current SI
unit.
Default: DekaNeutral Multiplier
Scale for neutral to be used with this data
object.
Default: NoneNeutral Scale
Unit for Neutral phaseDefault: DimensionlessNeutral Unit
Specifies the number of decimals shown
in HSI
0 to 9
Default: 0
Neutral Number of
Decimals
Specifies the multiplier for the current SI
unit.
Default: DekaPhase Multiplier
Scale for phases to be used with this data
object.
Default: NonePhase Scale
Unit for phasesDefault: DimensionlessPhase Unit
Specifies the number of decimals shown
in HSI
0 to 9
Default: 0
Phase Number of
Decimals
Phase Limit Value
Supervision
Maximum value for measurement.Default: 20000Max
Minimum value for measurement.Default: 0Min
Neutral Limit Value
Supervision
Maximum value for measurement.Default: 20000Max
Minimum value for measurement.Default: 0Min
Table 3.4.8.19-2 Additional configurable properties for Sub-Type WYE Full
DescriptionValue or Value range/ DefaultProperty/ Para-
meter
Subtype of WYEWYE FullSub-Type
Phase Limit Value
Supervision
High limit for measurement. Event is cre-
ated when value crosses the limit.
Default: 0High
High-high limit for measurement. Event is
created when value crosses the limit.
Default: 0High-High
