14
Hardware
3ADW000197R0101 DCS800-R Sel e a
Pre-assembled part
This part is pre-assembled and consists of:
- Housing for electronics (as shown on figure before)
- Control board SDCS-CON-4 built-in
- Electronic power supply SDCS-POW-4 built in (including flat cable to SDCS-
CON-4). This board needs to be feed by a 2-phase AC line voltage, either 115
V or 230 V
- Drive-to-drive interfacevia SDCS-DSL-4 board
- Control panel DCS800 CP
- Flat cable interconnection board SDCS-CCB4
Hint: The older version of the electronic power supply SDCS-POW-1 can be used
as a spare part for the actual one, SDCS-POW-4.
As shown at the end of chapter Basic Selection some options can be ordered us-
ing a so called plus code. Such options most often can only be used together with
the controller board; sometimes they need to be plugged on the controller board to
get their function. Those options will be put at their correct place during production
and therefore will come within the housing.
Plug-in modules (e.g. Prfibus, I/O extensions) and the field supply FEX-425 Inter-
nal are parts handled by plus codes.
Loose parts
The kit is available as a 2-Q or 4-Q version. Both of them are available for power
parts with one up to four thyristors in parallel. Because of the different versions
some components will be part of the delivery in every case like the SDCS-PIN-51
and SDCS-REB-1 board, others depend on the configuration:
DCS800-R01 -0000-01
(1 bridge)
-0000-02
(2 bridges)
-0000-03
(3 bridges)
-0000-04
(4 bridges)
(2-Q)
1x PIN-48
- - - -
- - - -
2x PIN-48
2x QUINT-PS
1x REB-2
3x PIN-48
2x QUINT-PS
1x REB-2
4x PIN-48
2x QUINT-PS
1x REB-2
DCS800-R02 -0000-01
(1 bridge)
-0000-02
(2 bridges)
-0000-03
(3 bridges)
-0000-04
(4 bridges)
(4-Q)
2x PIN-48
- - - -
- - - -
4x PIN-48
2x QUINT-PS
1x REB-2
6x PIN-48
2x QUINT-PS
1x REB-2
8x PIN-48
2x QUINT-PS
1x REB-2
