Installation
3ADW000197R0101 DCS800-R Sel e a
Hints for Cabling
Each kit will be delivered already with most of the cables needed to do the com-
plete wiring. The next table lists the flat cables. Together with
65
HFigure 13 they can
be identified to use the right cable for any of the connections. In case there is more
than one connection between two or more boards (e.g. connection made by cable
B2) all the cables will have the same marking.
Marking at
66
HFigure 13
Order number Remark
A 3ADT 693567R1 2 cables per kit; 5 m long
B1 3ADT 693230R1 1...2 cables per bridge; 3 m long
B2 3ADT 693217R1 2...8 cables per kit; 5 m long
C GNT 6093268R6 2 cables per kit; 0.5 m long
D DCA 0020531P1
1x Resistor 2.21 k
Ω
E cable type: AWG20, UL10203,T
F DCA 0021154R0001 Adapters for different gate connections

ABB DCS800 Specifications

General

Control Type	Digital
Supply Voltage	380 ... 690 V AC
Input Voltage Range	380 V to 690 V AC
Control Mode	Torque, Speed
Cooling Method	Air-cooled
Communication Protocols	Modbus, Profibus, CANopen
Communication Options	Ethernet
Protection Class	IP21, IP54
Enclosure Rating	IP00, IP21, IP54
Protection	Overcurrent, Overvoltage, Overtemperature
Ambient Temperature	0 to 40°C
Field Supply	Integrated or External
