The boards serve for different purposes:
- SDCS-PIN-48:
Pulse transformer board is mounted on a card holder. For the interconnections
6 firing leads (twisted pair; system plug on one end) and a shielded flat cable
(round; 20-pole) will come with the kit. For cable length, please refer to chapter
Installation.
- SDCS-PIN-51:
Measuring board is mounted on a card holder. For the interconnections 5 leads
for the AC and DC voltage measurement (single core; 6,3 mm faston on one
end), 2 leads for the current measurement (twisted pair; system plug on one
end), 2 shielded flat cable (round; 16 pole) and a pluggable resistor for X22 will
come with the kit. For cable length, please refer to chapter Installation.
- SDCS-REB-1: (Interface board)
- QUINT-PS: (Power supply)
- SDCS-REB-2:
Pulse amplification board for more than one bridge in parallel is mounted on a
card holder. For the interconnections 2 flat cables (20-pole) will come with the
kit. For cable length, please refer to chapter Installation.
Optional parts
The options available differ in their usage. Some of them are related to the rebuild
kit, some to the drive itself or to the application the drive is used for:
- Subassembly SDCS-REB-3:
This board is used together with the SDCS-REB-2 and SDCS-PIN-48. With the
help of this board the firing pulse assignment can be changed and adapted to
the needs given by the existing power part construction. The board will come
mounted on a card holder. For the interconnections 4 flat cables (20-pole) will
come with the kit. For cable length, please refer to chapter Installation.
- Plus code +S164 (FEX-425 Internal):
This field supply can be build into the electronic housing. When ordered using
the plus code it will be mounted inside the housing during production. The board
can be connected to any 2- or 3-phase power supply with up to 500V.
Power rating:
with 2-phase supply: 16A max !
with 3-phase supply: 25A max !
When doing the engineering please make sure all conditions for the power sup-
ply configuration are taken into consideration.
- Subassembly SDCS-IOB-2x/IOB-3:
This subassembly is a part of the accessories of the DCS800-S0x converter
module. In case the inputs or outputs available at the controller board directly
do not fulfill the criteria concerning the input or output voltage range or the crite-
ria of the input / output to ground this option may be a solution.
The subassembly needs to be placed close to the electronic housing.
Depending on the overall configuration and the needs caused by the application
itself it may be necessary to add other options. These options should be selected
based on the overview of the DCS800-R system shown at the end of chapter Basic
Selection.
