NoteAction
xx1400001146
Fit the customer plate.4
M6x16 8.8-A2F (4 pcs)
xx1400001140
Fit the adapter complete to the customer plate.5
xx1400001141
Fasten the adapter complete to the customer
plate.
6
M6x16 8.8-A2F (2 pcs)
xx1400001142
Fit the R1.CP/CS cable to the customer plate.7
Continues on next page
96 Product manual - DressPack/SpotPack IRB 8700
3HAC055802-001 Revision: B
© Copyright 2015-2017 ABB. All rights reserved.
2 Installation
