122 EL3000 CONTINUOUS GAS ANALYZERS | OI/EL3000-EN REV. D
… 9 Calibration
… Automatic calibration: settings
Calibration method (automatic)
Analyzer
Calibration method
Remark
Uras26
Zero point / end-point calibration
Cannot be changed.
Limas23
Zero
point / end-point calibration
Cannot be changed.
Magnos206
Zero point
/ end-point calibration or substitute gas
calibration or single
-point calibration
If a substitute gas component is set up in the
Magnos206 analyzer, the calibration
method is factory
-set to substitute gas calibration, otherwise the zero point / end-
point calibration is set. Alternatively, single
-point calibration can be selected.
See also page 130.
Magnos28
Zero point
/ end-point calibration or substitute gas
calibration or single
-point calibration
If a substitute gas component is set up in the
Magnos28 analyzer, the calibration
method is factory
-set to substitute gas calibration, otherwise the zero point / end-
point calibration is set. Alternatively, single
-point calibration can be selected.
See also
page 131.
Magnos27
Zero point
/ end-point calibration or substitute gas
calibration
If a substitute gas component is set up in the
Magnos27 analyzer, the calibration
method is factory
-set to substitute gas calibration, otherwise the zero point / end-
point calibration is set.
See also page 133.
Caldos27
Zero point
/ end-point calibration or single-point
calibration
With standard gas, this cannot be changed.
Fidas24
Substitute gas calibration
Cannot be changed.
Oxygen sensor
S
ingle-point calibration
Cannot be changed.
