EL3000 CONTINUOUS GAS ANALYZERS | OI/EL3000-EN REV. D 43
5 Installation
Unpacking the Gas Analyzer
Injury hazard due to heavy weight
Depending on the version, the gas analyzer weighs7 to 15 kg
(19” housing – model EL3020) or 13 to 21 kg (wall-mounted
housing – model EL3040)!
• Two persons are required for unpacking and
Check the devices immediately after unpacking for possible
damage that may have occurred from improper transport.
Details of any damage that has occurred in transit must be
recorded on the transport documents.
All claims for damages must be submitted to the shipper
without delay and before installation.
1. Remove the accessories (refer to Scope of delivery on
page 15) from the transport carton.
Take care not to lose any of the accessories.
2. Remove the gas analyzer from the carton, together with the
padding material.
3. Remove the padding material and place the gas analyzer in a
clean area.
4. Clean the adhesive packaging residue from the gas analyzer.
Note
Keep the shipping carton and cushioning material for future
transportation.
Name plate
Contents of the name plate
The name plate contains the following information:
• Production Number (P-No.),
• Order Number (O-No.),
• Power supply (voltage, frequency, max. power
consumption),
• Installed analyzers with measurement components and
measuring ranges.
Analyzer data sheet
Contents
The analyzer data sheet contains the following information:
• Order Number (O-No.),
• Job number (J-No.)
• Production Number (P-No.),
• Production Date,
• Power supply
(voltage, frequency, max. power consumption),
• Measuring components and measuring ranges,
• Serial numbers of the installed modules.
Storage of the Analyzer Data Sheet
• on the left-hand side panel inside the 19″-housing (model
EL3020) and
• on the door glued inside the wall-mount housing (model
EL3040).
Note
• Keep the analyzer data sheet in the gas analyzer so that it is
always at hand, especially in case of service/maintenance,
refer to Notify Service on page 176.
• During commissioning, observe the information in the
analyzer data sheet. The information given in the analyzer
data sheet may differ from the general information in this
regard Operating Instruction.
