ABB EasyLine EL3000 User Manual

EL3000 CONTINUOUS GAS ANALYZERS | OI/EL3000-EN REV. D 171
No.
Status
Message
Reaction/troubleshooting
358
W
a
The intensity measured at the receiver up
-scales or down-scales the
limit value 1.
Notify Service.
359
A
S
a
The intensity measured at the receiver up
-scales or down-scales the
limit value 2.
Notify Service.
360
A
S
a
The filter wheel could not be initialized.
If the status message is pending for more than 5 minutes, the filter
wheel is blocked. Notify Service.
362
A
S
a
The calibration filter wheel could not be initialized.
If the status message is pending for more than 5 minutes, the
calibration filter wheel is blocked. Notify Service.
378
A
S
aL
Chopper wheel is blocked.
Visual inspection. Notify Service.
379
A
S
aL
Chopper wheel speed not OK.
Notify Service.
380
A
S
aL
Faulty IR beam or electronics.
Notify Service.
381
A
S
aL
High voltage defective on the preamplifier.
Notify Service.
382
A
S
aL
Measured value is influenced by vibrations.
390
A
S
aQ
Failure of the internal power supply. Notify Service!
Notify Service.
397
A
S
a
The temperature controller sensor is faulty.
Notify Service.
398
A
S
aL
No new measured values from the analog/digital converter.
Notify Service.
399
A
S
a
The measured value exceeds the value range of the
analog/digital
converter.
Check sample gas concentration. Check connectors on the gas
analyzer. Notify Service.
400
A
S
a
A calculation error occurred while calculating the measured value.
Power-up and power-down the power supply. Notify Service.
401
W
a
The flow up
-scales or down-scales the top or bottom limit value 1. Check measuring gas path. Notify Service.
402
A
S
a
The flow up-scales or down-scales the top or bottom limit value 2.
Check measuring gas path. Notify Service.
403
A
S
a
The
position value of the flow controller is outside the valid area. Notify Service.
404
A
S
a
The temperature exceeds or falls below the top or bottom limit value
2.
Notify Service.
411
F
S
a
The analyzer is in standby.
Reactivation in menu:
‘Operation
/ Pump/Standby / Fidas/Standby / Fidas /Restart’
Restart Fidas24.
412
F
S
a
Ignition failed. The analyzer needs to be reactivated manually.
Reactivation in menu:
‘Operation / Pump/Standby / Fidas/Standby / Fidas /Restart’
Check operating gases.
Restart Fidas24.
413
A
S
aL
Failure of auxiliary current in the analyzer hardware.
Notify Service.
414
F
S
a
The position value of this controller is below the permissible range.
(< 20%)
Check operating gases and connection leads.
Restart Fidas24, where applicable. Notify Service.
415
F
S
a
The position value of this controller is above the permissible range.
(>
90%)
