54 EL3000 CONTINUOUS GAS ANALYZERS | OI/EL3000-EN REV. D
… 5 Installation
… Position and design of the gas connections
Uras26: Gas connections for pipelines
(internal gas lines made stainless steel pipes)
Pos.
Connection
Supplementary information
Version
6
Pressure sensor
—
Screwed connections with hose nozzles (stainless
steel
1.4305) for hoses with 4 mm inside diameter
(included in scope of supply)
11
Sample gas inlet
—
⅛ NPT female thread (stainless steel 1.4305) for
threaded connections
(not included in scope of supply)
12
Sample gas outlet
For a sample cell
13
Sample gas outlet
For two sample cells in series
Note
The oxygen sensor, the ‘integrated gas feed’ option and the version with separated gas paths are not possible.
Magnos28: Gas Connections
Pos.
Connection
Supplementary information
Version
1
Sample gas inlet
—
⅛ NPT female thread (stainless steel 1.4305)
•
Connection of hose lines:
straight screw-
in socket (PP) with hose nozzles
for hoses with inside diameter 4 mm
(included in scope of delivery)
•
Connection of piping:
screw-in fittings
(not included in scope of delivery)
2
Sample gas outlet
—
Note
The sample gas inlet of Magnos28 can be optionally connected at the factory to the sample gas output (gas path 1) of Uras26 or have
a separate sample gas path without connection to Uras26.
