Operation Manual / A130-M.. - A145-M..
13 Spare parts / 13.1 Ordering spare parts
© Copyright 2022 ABB. All rights reserved. HZTL4031_EN Rev.P February 2022
13 Spare parts
13.1 Ordering spare parts
CAUTION
Spare part storage
All spare parts that were ordered together with the turbocharger must be
kept intact and ready for use.
u Carefully clean any rusted parts and grease them.
Please quote the following data when making queries and ordering spare parts:
¡ Turbocharger type
¡ Serial number of the turbocharger
¡ Designation and part number.
Spare parts can be ordered from any Turbo Systems Service Station.
u If different model variants are not taken into account in this document, contact an Turbo
Systems Service Station.
u Dispose of placed and unusable parts in an environmentally-friendly and professional
manner in accordance with the local regulations.
u Dispose of the packaging of new parts in an environmentally-friendly and professional
manner in accordance with the local regulations.
13.2 Required customer spare part set (97070)
For the work described in the Operation Manual, the customer spare part set(97070) is re-
quired. These parts are only available in the complete set.
Customer spare part set
97070 Designation Quantity
42012 O-ring 1
61002 * Gasket 1
61008 * Gasket 1
77005 O-ring 1
79041 Counter-sunk screw 2
81010/ 82010 O-ring 1
Table50: Customer spare part set 97070
* This gasket can only be installed when a gas outlet casing from Turbo Systems is used.
Page 129 / 149
