Operation Manual / A130-M.. - A145-M..
4 Commissioning / 4.2 Inspection procedures
© Copyright 2022 ABB. All rights reserved. HZTL4031_EN Rev.P February 2022
Water-cooled bearing casing
CAUTION
Failure of bearing casing cooling
Any prolonged failure of the water cooling will shorten the lifetime of the
turbocharger.
u Make sure that an uninterrupted supply of cooling water is provided dur-
ing operation.
u Check whether water pipes are fitted on the bearing casing.
4.2.3 Checks after commissioning (engine in idle mode)
Lubricating system
u Observe lubricating oil pressure at inlet upstream of turbocharger.
u Observe lubricating oil temperature at inlet upstream of turbocharger.
u For permissible values, see chapter Monitoring operation →49.
Leaktightness of pipes
WARNING
Risk of burning from hot gas
Escaping gases are hot and will lead to serious burns in the event of contact.
u Check all pipes for leaks in accordance with the enginebuilder’s instruc-
tions.
Wear safety gloves to protect against thermal hazards.
4.2.4 Checks when starting up the engine
If present:
u Measure speed, oil pressure and charging pressure at various engine performances.
u Measure the exhaust gas temperature before and after the turbine.
u Measure the air temperature before and after the compressor.
u Compare the measured values with the values of the acceptance report. Different operat-
ing conditions indicate a malfunction (see chapter Eliminating malfunctions →82).
Lubricants and pastes used during assembly can liquefy or vaporise and escape as oily fluids
during the initial hours of operation. Continual escape of an oily fluid indicates an oil leak. In
the event of a leak, contact a Turbo Systems service station.
Page 47 / 149
