1.2.2 Functional overview
FCA/S 1.1.1.2
FCA/S 1.1.2.2
FCA/S 1.2.1.2
FCA/S 1.2.2.2
Inputs
3
3
3
3
Switch sensor, e.g. window contact
1
1
1
1
Value/forced operation, e.g. operating
mode
1
1
1
1
Temperature sensor, e.g. exhaust
temperature
1
1
1
1
Outputs 6 A switch
3
3
3
3
3-speed fan or
1
1
1
1
2-speed fan or
1
1
1
1
1-speed fan or
1
1
1
1
3 individual outputs
3
3
3
3
Outputs 16 A (10 AX) switch
1
-
1
-
Electrical auxiliary heater
1
-
1
-
Outputs 20 AX switch
-
1
-
1
Electrical auxiliary heater
-
1
-
1
Outputs electronic 0.5 A
4
4
-
-
Thermoelectric Valve Drives (PWM)
4
4
-
-
Motor-Driven Valve Drives (3-point)
2
2
-
-
Outputs analog 0...10 V
-
-
2
2
Analogue Valve Drives
-
-
2
2
