Commissioning
FCA/S 1.x.x.1 | 2CDC508134D0202 165
Enable communication object
"Status Switch" 1-bit
Options:
No
Yes
Selection of option Yes.
Dependent parameters:
Send object value
Options:
No, update only
On change
After request
After a change or request
 No, update only: The status is updated but not sent.
 On change: The status is sent when a change occurs.
 After request: The status is sent when a request occurs.
 After a change or request: The status is sent on a change or a request.
Object value of contact position
Options:
1 = closed, 0 = open
0 = closed, 1 = open
This parameter defines the communication object value of the switch status (Status switch).
 1 = Closed, 0 = Open: A closed contact is represented by communication object value 1 and
an open contact is represented by the value 0.
 0 = Closed, 1 = Open: A closed contact is represented by communication object value 0 and
an open contact is represented by the value 1.
Note
The contact position and thus the switch status can be the result of a series of priorities and
links.
