Commissioning
188 2CDC508134D0202 | FCA/S 1.x.x.1
In the following table, the Forced operation function is explained:
Bit 1
Bit 0
Access
Description
0
0
Enabled
The communication object Switch of the actuator is enabled by the binary input. The
assigned sensor can control the actuator via the Switch communication object. The binary
input does not control the actuator. Bit 0 of the value of the Forced operation
communication object is not evaluated. The Forced operation communication object sends
a telegram with the group addresses of the Forced operation communication object and
the status of the Switch communication object with every state change of the Switch
communication object.
0
1
Enabled
1
0
Off
The communication object Switch of the actuator is disabled by the binary input. The
assigned sensor cannot control the actuator via the Switch communication object. The
binary input controls the actuator via the Switch communication object. The actuator is
switched off. Bit 0 of the value of the Forced operation communication object is evaluated.
1
1
On
The communication object Switch of the actuator is disabled by the binary input. The
assigned sensor cannot control the actuator via the Switch communication object. The
binary input controls the actuator via the Forced operation communication object. The
actuator is switched on.
8-bit scene [1…64]
Options:
1…64
This parameter defines the scene number, which is sent on actuation.
Recall/store scene
Options:
Recall
Save
This parameter defines whether the scene is to be recalled or stored.
Hour [0...23]
Options:
0…23
Minute [0...59]
Options:
0…59
Seconds [0…59]
Options:
0…59
With these parameters, the hours, minutes and seconds are set which are to be send when
actuated.
Weekday [1 = Mo, 2..6, 7 = Su]
Options:
0 = no day
1 = Monday
2 = Tuesday
3 = Wednesday
4 = Thursday
5 = Friday
6 = Saturday
7 = Sunday
Using these parameters, the weekday sent on actuation is set.
