ABB i-
bus
®
KNX
Commissioning
86
2CDC50813
4D0202 | FCA/S
1.x.x.1
Fan Coil operating mode: 2 control values/1 valve / with switching object
What does the option control value input:
"2 control values/1 valve / with switching object"
mean?
Example: Valve and three-speed fan
Control value processing in the device
Analog:
Output A
Output C
Control va
l
ue input
2 control
values/ 1 val
ve/
with sw
it
ching obje
ct
-
Motor-driven (3-point):
Output A/B
Output C/D
Control va
l
ue input
2 control
values/ 1 val
ve/
with sw
it
ching obje
ct
-
= Control value functions
- = Control value does not function
87
89
