1 Description
1.1.3 Definition of version designation
10 Rev.N 3HAC9117-1
Power consumption
Path E1-E2-E3-E4 in the ISO Cube, maximum load.
IRB 4400/45 (Cube side = 630 mm)
IRB 4400/60 (Cube side = 630 mm)
Figure 2 Path E1-E2-E3-E4 in the ISO Cube, maximum load.
Speed [mm/s] Power consumption [kW]
Max. 1.36
1000 0.95
500 0.74
100 0.62
Speed [mm/s] Power consumption [kW]
Max. 1.33
1000 0.99
500 0.78
100 0.66
