Overview
3HAC9117-1 Rev.N 5
Overview
About this Product specification
It describes the performance of the manipulator or a complete family of manipulators
in terms of:
• The structure and dimensional prints
• The fulfilment of standards, safety and operating requirements
• The load diagrams, mounting of extra equipment, the motion and the robot reach
• The specification of variant and options available
Users
It is intended for:
• Product managers and Product personnel
• Sales and Marketing personnel
• Order and Customer Service personnel
Contents
Please see Table of Contents on page 3.
Revisions
Revision Description
Revision 8 - New values for Performance Acc. to ISO 9283 added
- M2000 cancelled.
Revision J - Foundry Prime added
- Option 287-5 Wash removed
Revision K - Text added to “Clean room robots”
- Footnote added to “Pose accuracy”
Revision L - Changes in chapter Standards
- Directions of forces
- Warranty information for load diagrams
Revision M - Maximum load and moment of inertia for full axis 5 movement
- Wrist torque
Revision N - Changes for Calibration data
- Work range
- Explanation of ISO values (new figure and table)
- Stopping distance
- User documentation on DVD
