ABB MicroFlex e150 - Effect of Output Current on DC-Bus Ripple Voltage

Technical data 131
 Effect of output current on DC-bus ripple voltage
20
0
10
20
30
40
50
60
30 40 50 60 70 80 90 100 110 120 130 140 150
Single-phase AC supply
Three-phase AC supply
% of drive rated current
DC-bus ripple voltage (V
pk-pk
)
