Technical data 147
 Digital inputs DIN4 - DIN9 (OPT1)
 Digital outputs DOUT0 (Status), DOUT1, DOUT2 (X3)
 Digital outputs DOUT3 - DOUT6 (OPT1)
Description Unit All models
Type Opto-isolated inputs
Input voltage
Nominal
Minimum
Maximum
Active
Inactive
VDC
24
12
30
> 12
< 2
Input current (maximum, per input) mA 50
Sampling interval ms 1
Minimum pulse width µs 5
Description Unit All models
User supply (maximum) V DC 28
Output current (maximum) mA 100
Fuse:
Approximate trip current
Reset time
mA
s
200
< 20
Update interval ms 1
Description Unit All models
User supply (maximum) V DC 28
Output current (maximum) mA 100
Fuse:
Approximate trip current
Reset time
mA
s
200
< 20
Update interval ms 1
