Electrical installation: input / output 59
Electrical installation:
input / output
What this chapter contains
The chapter describes how to connect low voltage control signals.
The following conventions will be used to refer to the inputs and outputs:
I/O . . . . . . . . . . . Input / Output
AIN . . . . . . . . . . Analog Input
AOUT . . . . . . . . Analog Output
DIN . . . . . . . . . . Digital Input
DOUT . . . . . . . . Digital Output
STO. . . . . . . . . . Safe Torque Off
WARNING! The work described in this chapter may only be carried out by a
qualified electrician. Follow the instructions in chapter Safety on page 11.
Ignoring the safety instructions can cause injury or death.
Make sure that the drive is disconnected from the input power during
installation. If the drive is already connected to the input power, wait for 5
minutes after disconnecting the input power.
